Before major re-wire and re-routing of the wires. Fuse box is in upper right corner, a switch panel is lying face down on transmission tunnel

DME mounted on project box that houses relays and multipin connectors for protection, and ease of service.

Quarter turn camlocs secure the CF panel to the old vent and radio/Heater control area.

Hoping the image shows the labels and better knob choices for the wiper and cool suitOverall, much cleaner than it has been.  The glare of the prior "on/off" switch backing plates is gone.Close up of how the DME is mounted to a Radio Shack box (protects the X20 connector and its sibling) for quick release.
